1. Product Model: JL-250T
2. Rated Voltage: 0-480VAC
3. Flammability Rating: UL94-0
4. Leads Gauge: #14, #18
5. Compliant Standard: ANSI C136.41, CE, ROHS, UL
|
Product Model |
JL-250T |
|
|
Power Volt Range |
0~480VAC |
|
|
Rated Frequency |
50/60Hz |
|
|
Power Loading |
15A max. / AWG#16: 10A max. |
|
|
Signal Loading |
30VDC, 0.25A max. |
|
|
Ambient Temperature External* |
-40℃ ~ +70℃ |
|
| Material |
Receptacle |
UV stabilized Polycarbonate (UL94 5VA) |
|
Power Contact |
Solid Brass |
|
|
Signal Contact |
Nickel-plated Phosphor Bronze, Gold plated |
|
|
Gasket |
Thermal Elastromer (UL94 V-0) |
|
|
Leads |
12″ |
|
|
Overall Dimensions (mm) |
65Dia.x 38 |
|
* wire outlets glued
* optional choose custom receptacle wire is be used in external forced connector cable;
* this 250T series receptacle with 5p or 7p;
* this leads with length at least 12 inch;
*Additionally, this lead is made from cable. If you require an extended length of cable lead, please feel free to get in touch.
–
Model:
At here, we offer NEMA series products, including photocontroller bases, twist lock photocell receptacles, and street light bases. These products include NEMA 7 PIN, NEMA 5 PIN, and NEMA 3 PIN options. For example, please refer to the graphics for the NEMA 7 PIN base or 3 PIN Base to match JL-208 shorting cap with the ANSI C 136.10 standard. Ensure that, when building your future municipal lighting project, you choose different types of portfolios in order to receive discounted bulk pricing and save on expensive shipping costs.
